JS-1T
The JS-1T is a multi-pattern studio microphone with three selectable polar patterns: Cardioid, Omnidirectional and Figure-8 providing superb performance for vocals, acoustic Instruments, drum kits, percussion etc. for either Live or Studio Recording.
SPECIFICATIONS
| JS-1T | |
| Type | Large Diaphragm Condenser Microphone |
| Frequency Response | 20~20,000 Hz |
| Sensitivity(at 1000Hz) | -38 dB* (12.6mV) 0dB=1V /Pa |
| Directional Pattern | Cardioid,Omnidirectional,figure-8 |
| Low Frequency Roll-off | 80Hz |
| Impedance | 200Ω |
| Max. SPL For 1% T.H.D. | 132 dB |
| Signal To Noise Ratio | 78dB |
| Power Supply | 36-52 VDC phantom power required |
| Current Consumption | 1mA |
| Output | 3 Pin XLR(M) (power module) |
| Net Weight | 480 grams(16.9oz) |
| Dimensions(mm) | Ø56mm(W)* 184mm(H) |
